A RIDING ARENA FOOTING PRIMER Horse people tend to be very particular in their likes and
dislikes. You can ask one hundred different horse people their opinion on one product and get almost one hundred different answers. Riding arena footing preferences are a
great example of this. Opinions and likes vary from discipline to discipline and even from person to person within each separate discipline. Footing is the material found on the
surface of an engineered riding arena. English arena riding falls basically into two categories: dressage and hunter/jumpers. Dressage enthusiasts typically like their
footing a bit deeper than the jumpers. In the western disciplines, footing depths are generally split into two categories: barrel racing and reining.
Here the reiners typically like their footing deeper than barrel racers. Footing depths generally vary between 2 and 5 inches, depending on material type and riding style.
The basic job of footing remains the same for all disciplines. It should cushion the horse’s
hooves, and provide Discipline-appropriate traction (which includes the ability of the reining horses to slide).
The footing should be non-toxic, odor free, and as dust free as possible. It should also be consistent through out the arena (i.e., level, of uniform depth and firmness, etc.).
When deciding which footing is right for you and your horses – ride it before you buy it. A particular footing or additive may feel great in your hand and feel completely different
under hoof. Find a facility that has the kind of footing you are considering and ride on it – most footing manufacturers can provide you with a list of farms using their product. It is
also recommended that you talk to the people who use it regularly and those responsible for maintaining it. Pertinent questions to ask include: How many riders use the arena per
day/week? When was the footing installed? How much did it cost (both material and installation)? How often is the arena groomed and with what tool? What they are using
for dust control – and if water, how much, how often, and how applied? Answers to these questions will help you decide on the best footing to meet your riding needs, budget, and
time/maintenance threshold.
The following sections describe a variety of footing materials and additives, but are by no means exhaustive. Every year
new products arrive on the market and many may prove to be excellent. In any event, it is important to have clear
expectations regarding the performance of your footing (as well as the manufacturer and the contractor installing the
material). Footing can be very costly to install and even more costly to replace if you are dissatisfied. So it is very important to do your homework and make your decisions wisely.
Another important rule of thumb when installing your footing – less is more. Even on the most tightly compacted base
there will be some co-mingling of base and footing (effectively increasing the volume of footing). Start with less
material than you think you will need because it is much easier to add additional material to your arena, than to remove it.
STONE DUST FOOTING Here in the east it is common to see arenas with a product known as
stone dust (a.k.a. blue stone or #10 screenings) as the footing. Typically stone dust is used as the engineered base of the riding arena because it
compacts well and does not contain large stones. Some excavators will compact the stone dust then add additional stone dust in its loose form as
the footing on top. It is more difficult to maintain this type of arena as the tendency is for all of the material to become highly compacted. With no
clear delineation between footing and base (as opposed to the footing in the next section) and the need for more frequent and aggressive harrowing
to keep the riding surface from becoming rock-hard, it requires a skilled operator to keep the compacted material level (it will tend to have rolling
waves) with a consistent “fluffy” layer above it. Stone dust is the lowest cost material to use as footing and may be
appropriate for you if the additional maintenance needs and the possibility of a less level surface will not adversely affect your riding.
SAND FOOTING By far the most common substance used for footing is sand. Sand is
most frequently used as a stand-alone footing, but is also the used with other lofting agents (see below). Sand placed over an engineered base
composed of compacted stone dust is fairly easy to maintain. Sand will not harden like stone dust and when dragging, one can differentiate
between fluffing the sand and harrowing into the base. Sand is the next most affordable footing material after stone dust. While there are a wide
variety of sands marketed to equestrians, a washed concrete sand (ASTM C-33) is a good place to start. To meet the American Society of
Testing and Materials (ASTM) specifications, all C-33 sands must meet specific particle size requirements (i.e., they are washed to remove fine,
dust-causing particles and screened to remove all larger pebbles and rocks). There are two broad categories of sand
available: manufactured sand which is produced as a product from rock crushing, and natural sand which is mined
from wherever it has been deposited (e.g., river bed sand or bank sand). The chemical composition of the material
from which the sand is made will also affect its performance in the ring. Generally speaking, a hard (e.g., quartz), angular C-33 sand will resist breakdown and provide good traction in your arena.
LOFTING AGENTS
People often prefer to add a lofting agent to sand to help with active recovery, retain moisture, and to add more
cushion and spring. This list is seemingly endless with new products coming on the market almost monthly. To date
there are three major categories on the market: rubber/plastic products, fiber products, and wood products.
Rubber Products A wide variety of rubber and plastic products are available for use as lofting agents for your
arena. Some, like crumb rubber (made from recycled tires), have been around for many years. Others, including
ground sneakers or tennis balls, shredded surgical rubber, and stripped electrical wire casings have come to market
more recently. Rubber lofting agents provide additional cushioning for your riding surface. In addition, many (the crumb
rubbers in particular) help retain moisture by some of the material “floating” to the top of the sand and creating a “lid”
to keep moisture in. the darker colored materials also absorb heat from the sun and will stay rideable longer in cold
weather than sand-only footings. When installed correctly, these footings can provide a low maintenance, all weather quality riding surface both indoors and out.
Any of these products may be ideal for your situation and many are quite costly. It is important to be clear on what you
are buying and what to expect. Even within the crumb rubber footings, cost, quality, and guarantees will vary greatly.
Again, try it before you buy it and look for clear (i.e., written) information on how the product will perform and how the manufacturer will stand behind their product.
Fabric/Fiber Products:
Fabric and fiber based lofting agents have been used in Europe for some time and are now finding their way into arenas
on this side of the Atlantic. Synthetic felt is ground into small pieces and mixed with sand. Alternatively, the short fibers
from which the felt is made is mixed with sand to create a cushioning and moisture retaining footing. The fabric or fibers
create virtually no dust as they wear. These footings are perhaps best suited for indoor arenas as the fibers and fabric
are quite light weight and have a tendency to be blown by the wind. As grinding the felt requires specialized machinery,
there are few sources for the material and it is fairly expensive. It generally performs at its best when installed in an indoor arena and is consistently watered with an irrigation system.
Wood Products
Wood products can provide cushioning and moisture retention for a sand-based footing. Chips and shredded material
can also vary in size and texture creating inconsistent footing. As they are organic, these products will eventually
decompose and lead to dusty (if dry) or compacted and/or slippery (if wet) conditions in your arena. Engineered wood
fiber products are more durable and consistent and reduce these issues. All wood products need to be replenished
every couple of years (depending on conditions, arena traffic, etc.). Peat moss is another wood product used as an
additive to arena footing. It can be mixed with other lofting agents to help maintain moisture content, but will only
perform well if monitored and watered consistently. If not maintained properly, the peat moss dries and footings can become quite slippery.
COATED SAND Another type of sand based footing is the polymer or wax coated sand. The polymer and wax coated sands are
guaranteed to be dust free. In creating these materials, each individual particle of sand is coated to prevent dust. The
material is engineered to have appropriate frictional characteristics for traction (it has the look and feel of brown sugar).
Since it requires no water, it does not freeze. It does not compact so requires only minor grooming. Manufacturers
offer differing claims of the durability of their products with the more durable being the more expensive. And expensive
it can be. Footing for a 20m by 60m ring can cost between fifty and one hundred thousand dollars.
DUST CONTROL Watering is still the most widely used form of dust control. It is safe and reliable. The most efficient method for
watering an indoor arena is an overhead system. Overhead systems are very expensive, but provide the most
consistent uniform coverage. Kickwall mounted rotor systems cannot provide even, consistent water coverage. By
design, the circular spray pattern creates areas where the rotors overlap (that will tend to be wet) and areas where
there are gaps between the sprays (that will be dry). This is less of an issue with outdoor arenas as rotors can be
designed to only have overlap and the sloped base allows excess water to flow off the ring (like when it rains). New
traveling irrigation systems are quite affordable and are very versatile in that you can use them in your indoor arena or outdoor arena. And they are quite efficient in putting down
even, consistent water over the entire arena.
Some facilities are mixing in magnesium chloride in lieu of using an irrigation system to maintain a dust free riding
environment. The main concern with magnesium chloride is the drying effect it may have on the horse’s hooves. If
using magnesium chloride for freezing prevention or dust control, it is recommended you frequently oil/moisturize the hooves and rinse the hooves off after riding on the footing.
Another dust control procedure involves spraying a non-toxic synthetic liquid over the footing. Similar in principle to
polymer coated sand, the liquid theoretically coats each particle of footing, trapping the dust in the sand. Regular
harrowing is required to keep the materials properly mixed. With continued riding, both the sand and the liquid will degrade requiring additional applications every 6 to 12 months depending on use.
Article by Michael M. Donovan – Arena Designer & Consultant
